Thickness : 15.20 mm Width : 50.00 mm
Height : (JNS35/7.5, JNS35/15, JNS32) : 62.00mm / 69.50mm / 67.00mm
| Rigid Conducto(mm2) | 0.75-16 |
| Flexible Conductor(mm2) | 0.75-10 |
| AWG | 0/1-18 |
| Rated Voltage (V) | 1000 |
| Rated Current (A) | 150 |
| Rated Connectiong Capacity(mm2) | 50 |
| Rated Surge Voltage | 8 |
| Contamination Class | 3 |
| Overvoltage Category | Ⅲ |
| Material Grop | Ⅰ |
| Rigid Conducto(mm2) | 0.75-50 |
| Flexible Conductor(mm2) | 0.75-35 |
| AWG | 0-18 |
| Rated Voltage (V) | 1000 |
| Rated Current (A) | 150 |
| Insulation Material | PA |
| Inflammability Class | UL94,V-0 |
| Stripping Length mm | 16 |
| Screw M | 6 |
| Torque N.m | 3.2-3.7 |
| Packing Quantity PCS | 25 |
| End Cover | - |
| Fixed Bridge | - |
| Insertion Bridge | - |
| Switch bar for 2 TB | - |
| Separating Disk | A048-9 |
| Partition Plate | - |
| Test Socket | - |
| Marker Strip | A050-10-5 |
| Marker Carriers | RBJ1 |
| Rail Stator | GD001 |
| Rail Stator | A047-9 |
| Rail Stator | A049-9 |
| MountingRail | JNS35/7.5 |
| MountingRail | JNS35/15 |
| MountingRail | JNS32 |
