Thickness : 8.20 mm Width : 42.50 mm
Height : (JNS35/7.5, JNS35/15, JNS32) : 47.00mm / 54.50mm / 52.00mm
| Rigid Conducto(mm2) | 0.2-2.5 |
| Flexible Conductor(mm2) | 0.2-2.5 |
| AWG | 8-26 |
| Rated Voltage (V) | - |
| Rated Current (A) | - |
| Rated Connectiong Capacity(mm2) | 10 |
| Rated Surge Voltage | 8 |
| Contamination Class | 3 |
| Overvoltage Category | Ⅲ |
| Material Grop | Ⅰ |
| Rigid Conducto(mm2) | 0.2-10 |
| Flexible Conductor(mm2) | 0.2-6 |
| AWG | 8-24 |
| Rated Voltage (V) | - |
| Rated Current (A) | - |
| Insulation Material | PA |
| Inflammability Class | UL94,V-0 |
| Stripping Length mm | 10 |
| Screw M | 4 |
| Torque N.m | 1.5-1.8 |
| Packing Quantity PCS | 20 |
| End Cover | - |
| Fixed Bridge | - |
| Insertion Bridge | - |
| Switch bar for 2 TB | - |
| Separating Disk | - |
| Partition Plate | - |
| Test Socket | - |
| Marker Strip | A005-10-5 |
| Marker Carriers | RBJ1 |
| Rail Stator | GD001 |
| Rail Stator | A047-9 |
| Rail Stator | A049-9 |
| MountingRail | JNS35/7.5 |
| MountingRail | JNS35/15 |
| MountingRail | JNS32 |
